MC-7200 StormTech Technical Specifications

Filename:
MC-7200 StormTech Technical Specifications.dwg

 MC-7200 StormTech Technical Specifications

StormTech MC-700 StormTech Chamber system specifications state that only chambers that are manufactured by ADS and approved by site engineers will be used. Chambers will meet the requirements of ASTM F2418-16a, Chamber shall be designed, tested and allowable load configurations determined in accordance with ASTM F2787.

MC-7200 technical detail with chamber specifications, nominal end cap specifications, part numbers and drawings are shown. The side view shows the valley stiffening rib, crest, web, upper joint corrugation, crest stiffening rib, foot and lower joint corrugation.

Custom prefabricated inverts are shown. Manifold and end cap cut notes are included.

A part number chart lists measurements for stub, A/B/C dimensions.
